LMK8UU Square Flanged Linear Bearing


Cinque TerreCinque Terre
SKU: 3208152450

This is a LMK8UU Square Flanged Linear Bearing to suit 8mm shafts.

Its inner diameter is 8mm, its outer diameter is 15mm, and its length is 24mm. Square flanged length is 25mm x 25mm. It's Pitch Circle Diameter (PCD) is 24mm.

Specs:

Bearing Model: LMK8UU
Inner Diameter (d): 8 mm
Outer Diameter (D): 15 mm
Length (L): 24 mm
K: 25 mm
Dp: 24 mm
t: 5 mm
X: 3.5 mm
Y: 6.5 mm
Z: 3.1 mm
Dynamic Loading (CN): 27.9402242355952 kg/m
Static Loading (CoN): 39.9728755487348 kg/m


NZ $12.00 each

In Stock Now
