LMK13UU Square Flanged Linear Bearing


Cinque TerreCinque Terre
SKU: 3213233215

This is a LMK13UU Square Flanged Linear Bearing to suit 13mm shafts.

Its inner diameter is 13mm, its outer diameter is 23mm, and its length is 32mm. Square flanged length is 34mm x 34mm. It's Pitch Circle Diameter (PCD) is 33mm.

Specs:

Bearing Model: LMK13UU
Inner Diameter (d): 13 mm
Outer Diameter (D): 23 mm
Length (L): 32 mm
K: 34 mm
Dp: 33 mm
t: 6 mm
X: 4.5 mm
Y: 8 mm
Z: 4.1 mm
Dynamic Loading (CN): 52.0055268618743 kg/m
Static Loading (CoN): 79.9457510974696 kg/m


NZ $14.00 each

In Stock Now
