LMEK20UU Square Flanged Linear Bearing


Cinque TerreCinque Terre
SKU: 3220324567

This is a LMEK20UU Square Flanged Linear Bearing to suit 20mm shafts.

Its inner diameter is 20mm, its outer diameter is 32mm, and its length is 45mm. Square flanged length is 42mm x 42mm. It's Pitch Circle Diameter (PCD) is 43mm.

Specs:

Bearing Model: LMEK20UU
Inner Diameter (d): 20 mm
Outer Diameter (D): 32 mm
Length (L): 45 mm
K: 42 mm
Dp: 43 mm
t: 8 mm
X: 5.5 mm
Y: 9.5 mm
Z: 5.1 mm
Dynamic Loading (CN): 87.8995375586974 kg/m
Static Loading (CoN): 139.701121177976 kg/m


NZ $18.00 each

In Stock Now
