F17x30x7 mm (F6903-ZZ) Flanged Bearing


Cinque TerreCinque Terre


SKU: 1730703315

This 17 x 30 x 7 mm (F6903-ZZ) bearing is a metric flanged ball bearing. The F6903-ZZ inner diameter is 17 mm, the F6903-ZZ outer diameter is 30 mm, the F6903-ZZ width is 7 mm.

This bearing has non-contact metal shields on both sides to protect the bearing from dust or any possible contamination, which can extend bearing life, and retain the lubricant in the bearing.

Specs:


Bearing Model: F6903-ZZ
Inner Diameter (d): 17 mm
Outer Diameter (D): 30 mm
Width (B): 7 mm
Flange Dia. (Df): 32.5 mm
Flange Thickness (Cz): 1.5 mm
Dynamic Load (Cr): 4.588 kN
Static Load (Cor): 2.565 kN
Material: GCR15 Bearing Steel
Closures: Metal Shielded Both Sides

NZ $5.50 each



Not in stock
Available for delivery within 5 - 10 working days
