F10x15x4 mm (F6700-ZZ) Flanged Bearing

NZ $3.50 +GST each

In Stock Now

SKU: 101504101

This 10 x 15 x 4 mm (F6700-ZZ) bearing is a metric flanged ball bearing. The F6700-ZZ inner diameter is 10 mm, the F6700-ZZ outer diameter is 15 mm, the F6700-ZZ width is 4 mm.

This bearing has non-contact metal shields on both sides to protect the bearing from dust or any possible contamination, which can extend bearing life, and retain the lubricant in the bearing.


Bearing Model: F6700-ZZ
Also Known As: F6700-ZZ
Inner Diameter (d): 10 mm
Outer Diameter (D): 15 mm
Width (B): 4 mm
Flange Diameter (Df): 16.5 mm
Flange Thickness (Cz): 0.8 mm
Dynamic Load (Cr): 0.855 kN
Static Load (Cor): 0.435 kN
Material: GCR15 Bearing Steel
Closures: Metal Shielded Both Sides
