17x30x7 mm (6903-ZZ) Bearing

NZ $4.10 +GST each

In Stock Now

SKU: 173007001

This 17 x 30 x 7 mm (6903-ZZ) bearing is a metric deep groove ball bearing. The 6903-ZZ inner diameter is 17 mm, the 6903-ZZ outer diameter is 30 mm, the 6903-ZZ width is 7 mm.

This bearing has non-contact metal shields on both sides to protect the bearing from dust or any possible contamination, which can extend bearing life, and retain the lubricant in the bearing.


Bearing Model: 6903-ZZ
Also Known As: 6903-ZZ, 61903
Inner Diameter (d): 17 mm
Outer Diameter (D): 30 mm
Width (B): 7 mm
Min. Chamfer (r): 0.3 mm
Dynamic Load (Cr): 4.60  kN
Static Load (Cor): 2.60  kN
Max. Speed (Grease): 19000 RPM
Max. Speed (Oil): 24000 RPM
Series: 6900
Material: GCR15 Bearing Steel
Closures: Metal Shielded Both Sides

Search Keywords: 17x30x7mm6903ZZBearing,6903ZZ,6903-Z,6903ZZ6903ZZ,61903,6903-Z, 61903,6903ZZ, 61903
